From Engineering Drawing to USA Delivery in 7 Days
How Manufyn manufactured and delivered 10 precision CNC machined aluminum components for a US robotics customer at just $6 per part.
Rapid CNC Machining for a US Robotics Customer
A robotics customer based in the USA approached Manufyn for a small batch of precision CNC machined aluminum components required for a robotic gripper application.
The requirement was for 10 components with a highly compressed delivery schedule. Manufyn coordinated engineering drawing review, CNC milling, dimensional inspection and international delivery.
The component was specified as an AD-100 Vertical Plate for a 2FGP20 OnRobot gripper. The drawing specifies Aluminum 1060, natural finish and an overall size of 1/4″ × 85 × 190 mm.
Small Quantity. Fast Turnaround. Global Delivery.
Robotics companies often require machined components in small quantities for prototype assemblies, testing, validation and early production.
For this project, the customer required only 10 components but needed the complete order delivered to the USA within just 7 days.
The challenge was therefore not simply machining the component. Manufyn had to coordinate manufacturing, inspection and international logistics within the same compressed timeline.
The AD-100 drawing was reviewed for material, dimensions, holes and machining requirements.
Aluminum 1060 was machined using CNC milling to produce the required profile and features.
The completed components were inspected using Trimos measurement equipment.
The completed quantity of 10 parts was dispatched for delivery to the customer’s location in the USA.
AD-100 CNC Machined Vertical Plate
The engineering drawing defines the component as a vertical plate for a 2FGP20 OnRobot gripper. The specified material is Aluminum 1060 with a natural finish.
| Specification | Drawing Requirement |
|---|---|
| Part Number | AD-100 |
| Part Name | Vertical Plate |
| Application | 2FGP20 OnRobot Gripper |
| Material | Aluminum 1060 |
| Overall Thickness | 1/4″ / 6.35 mm |
| Overall Dimensions | 85 × 190 mm |
| Linear Feature | 82 mm |
| Linear Feature | 186 mm |
| Repeated Spacing | 41.5 mm |
| Hole Dimension | Ø6.5 mm |
| Additional Hole | Ø5.5 mm |
| Feature Dimension | 3.37 mm |
| Angular Feature | 90° |
| Finish | Natural |
| Inspection | Trimos |
CNC Milling for a Low-Volume Robotics Component
CNC milling was selected for the component because the requirement involved a small quantity and a short development timeline. This allowed Manufyn to manufacture the aluminum component without dedicated production tooling.
Aluminum CNC Machining
The component was manufactured from Aluminum 1060 using CNC milling.
Low-Volume Manufacturing
The order consisted of 10 components, making CNC machining suitable for this robotics requirement.
Quality Inspection
Finished components were inspected using Trimos measurement equipment before shipment.
CNC Machined Components for Robotics and Automation
CNC machining is widely suited to robotics and automation applications where engineers need custom metal components, precise mounting interfaces and rapid development without committing to high-volume tooling.
CNC Machining Resources for Engineers and Buyers
Explore practical manufacturing resources covering CNC machining, cutting tools, machining parameters, engineering drawings, workholding and production planning.
CNC Speeds and Feeds
Understand spindle speed, feed rate and machining parameters for CNC milling.
Read Guide →CNC Tool Runout
Learn how tool runout can affect machining accuracy, surface finish and tool life.
Read Guide →Carbide vs HSS Cutting Tools
Compare carbide and HSS tools for different CNC machining applications.
Read Guide →CNC Tool Coatings
Understand common cutting tool coatings and their role in CNC machining.
Read Guide →CNC Insert Selection
Learn the factors involved in selecting inserts for machining operations.
Read Guide →Rapid Prototyping
Explore rapid prototyping approaches for engineering and product development.
Explore Prototyping →More Manufacturing Projects by Manufyn
Explore additional manufacturing projects to see how Manufyn supports engineering teams with machining, injection molding, prototyping and global procurement.
Send Your Robotics Drawing to Manufyn
Have a robotic gripper, mounting plate, bracket, end-effector or other CNC machined component to manufacture?
Send us your 2D engineering drawing or 3D CAD model along with quantity, material and delivery location. Manufyn can coordinate manufacturing, inspection and international delivery from India.
CNC Machining for Robotics FAQs
Can Manufyn manufacture CNC machined parts for robotics?
Manufyn supports CNC machining requirements for robotic components, automation parts, mounting plates, brackets, gripper components and other engineered metal parts.
Can Manufyn manufacture low-volume CNC parts?
Yes. CNC machining can be used for prototypes, engineering samples, small batches and production components.
Can you manufacture aluminum CNC parts for robots?
Yes. Aluminum CNC machining is suitable for many robotics components including brackets, plates, adapters, fixtures and end-effector components.
How does Manufyn inspect CNC machined parts?
Inspection requirements are incorporated into the manufacturing workflow. For this project, dimensional inspection was performed using Trimos measurement equipment.
Can Manufyn deliver CNC machined parts to the USA?
Yes. Manufyn coordinates manufacturing in India together with international delivery for global engineering and procurement customers.
How can I request a CNC machining quotation?
Send your 2D engineering drawing or 3D CAD file along with material, quantity, required delivery date and delivery location. Manufyn can review the requirement and coordinate the manufacturing quotation.
